EasyStream ENC9 - 9 Channel 1080P60 HDMI Encoder

$1,187.00 + IVA INCLUIDO

$1,424.40 inc VAT

The ENC9 by EasyStream is a 1U rack mountable 9 input HDMI encoder capable of encoding 9 inputs simultaneously with a resolution up to 1080P60.

Each input can be dual encoded for a main and sub stream with multiple push streams to RMTP or SRT servers.

Input resolution - 1080P, 720P, 1600x1200, 1440x900, 1366x768, 1280x1024, 1024x768, 800x600, 640x480

Output resolution - 1080P, 720P, 360P, Custom

Transfer Protocol - RTSP, RTMP, RTMPS, HTTP, HLS, UDP, Unicast,...

Disponibilidad: Contactenos

The ENC9 by EasyStream is a 1U rack mountable 9 input HDMI encoder capable of encoding 9 inputs simultaneously with a resolution up to 1080P60.

Each input can be dual encoded for a main and sub stream with multiple push streams to RMTP or SRT servers.

Input resolution - 1080P, 720P, 1600x1200, 1440x900, 1366x768, 1280x1024, 1024x768, 800x600, 640x480

Output resolution - 1080P, 720P, 360P, Custom

Transfer Protocol - RTSP, RTMP, RTMPS, HTTP, HLS, UDP, Unicast, Multicast


main chip:	Hi3531DV100
CPU:	ARM Cortex A9 dual [email protected]
Memory:	2GB DDR3
Flash:	256MB Nand Flash


Wired interface:	10/100M/1000M RJ45 network port
Wireless interface:	Support USB wifi module, support USB 4G module
Transfer Protocol:	RTSP, RTMP, RTMPS, HTTP, HLS, UDP, Unicast, Multicast
ONVIF:	Apoyo


basic skills:	WEB configuration, parameter hot update, firmware upgrade, network setting, password management
Superposition of effects:	Logo, Watermark, Subtitle, Rolling Caption, Mosaic, Timestamp
Video mix:	Picture-in-picture, 4-picture, 9-picture, etc., support real-time switching, support mixing
Resource management:	Customize fonts, upload watermark Logo images
