COFDM Modulator - DVBT2

Convert HDMI input to H.264 DVBT2 output.

Code 122004
Video Inputs Input  HDMI
Resolution mode 480 p - 576 p - 720 p - 1080i - 1080p
Compresión H.264 - BITRATE 5-15 Mb/s
Audio Inputs HDMI
Sample rate HDMI (32 kHz / 44.1 kHz / 48 kHz)
Compression  AAC-LC - bitrate 128-384 Kb/s
DVB
Processing Table insertion PAT, PNT, SDT
Configuration
Channel/network name,
SID, LCN, TSID, ONID, NID,
versions, audio, video PID's
DVB-T output Output frequency / level 170-230 MHz + 470-862 MHz / >80 dBµV
Constellation - QPSK/16QAM/64QAM - 1/2, 2/3, 3/4, 5/6, 7/8
Guard interval 1/4, 1/8, 1/16, 1/32
MER mode K/8K - 35 dB
Mains Plug DC 2.1 mm +5V
Consumption 10 Watts
Dimension L x W x H 170 x 130 x 35 mm
Weight 0,6 kg
